KACE-C533
Wallmount Enclosure for Micro-ATX MB
· Front accessible with slim ODD
· Support up to 2 x 3.5" HDD + 1 x 2.5" HDD
· Support 4 x expansion slot
· Excellent cooling with 1 x 8cm fan + 2 x 6cm fan(2 ball bearing)
· Front accessible with slim ODD
· Support up to 2 x 3.5" HDD + 1 x 2.5" HDD
· Support 4 x expansion slot
· Excellent cooling with 1 x 8cm fan + 2 x 6cm fan(2 ball bearing)
Specification
| Front Panel | |
| Power Switch | 1(With LED Indicator) |
| LED Indicators | HDD x1 |
| USB Port | 2 |
| Slim Optical Drive Slot | 1 |
| Back Panel | |
| Standard I/O Shield | 1(Not Included) |
| Expansion Slot | 4 |
| Internal Structure | |
| System Cooling | 8cm Fan(2 Ball Bearing) x1 + 6cm Fan(2 Ball Bearing) x2 |
| Memory Height | Accept Standard Size |
| HDD/SSD # and type | 3.5" x2 + 2.5" x1 |
| Mechanical & Processing | |
| Dimensions | W:16"(407mm)11.7" x D:(296mm) x H:5.2"(132mm) |
| Applied M/B Form Factor | Micro-ATX / Mini-ITX |
| Material | SGCC |
| Surface | Black Wet Paint with Texture Coat |
| Colour | Black / Customizable Colour |
| Power Solution Option | |
| PSII Power Supply | PSII 300W/400W/500W Power Supply |
