TAWA-T1040
1U Industrial Rackmount Chassis for 4 x Pico-ITX systems
· Front accessible connectors with 4 x dual USB port
· Support 4 x 3.5" SATA tray
· Easy integration, powerful performance
· Front accessible connectors with 4 x dual USB port
· Support 4 x 3.5" SATA tray
· Easy integration, powerful performance
Specification
| Front Panel | |
| Power Switch | 1 x4 |
| LED Indicators | HDD x4; Power x4 |
| USB 2.0 Port | 2 x4 |
| HDD/SSD # and type | 3.5" x4 |
| Back Panel | |
| Standard I/O Shield | Rear I/O for VIA Pico-ITX P720/P830/P840 Accept Custom Made Rare I/O for Any Other Pico-ITX M/B |
| Internal Structure | |
| System Cooling | 4cm Fan(2 Ball Bearing) x2 |
| Memory Height | Accept Standard Size |
| HDD/SSD # and type | 2.5" x4 |
| Mechanical & Processing | |
| Dimensions | W:19.00"(482.6mm) x D:12.52"(318mm) x H:1.73"(43.9mm) |
| Applied M/B Form Factor | Pico-ITX |
| Material | Heavy Duty Cold-rolled Steel |
| Surface | Black Wet Paint with Texture Coat |
| Colour | Black / Customizable Colour |
| Power Solution Option | |
| External AC Adapter | 60W: Input(AC 100~240V); Output(DC 12V@5A) |
