TAWA-T1300
1U Industrial Rackmount Chassis for Micro-ATX System
· Simple assembling and easy system integration
· Support 2 x expansion slot for PCIe or PCI card
· Compact size with only 208.80mm in depth
· Simple assembling and easy system integration
· Support 2 x expansion slot for PCIe or PCI card
· Compact size with only 208.80mm in depth
Specification
| Front Panel | |
| Power Switch | 1 |
| LED Indicators | HDD x1; Power x1 |
| USB 2.0 Port | 2 |
| Back Panel | |
| Standard I/O Shield | With Universal I/O Shields |
| Expansion Slot | 2 |
| Internal Structure | |
| System Cooling | 4cm Fan(2 Ball Bearing) x4 |
| Memory Height | Accept Standard Size |
| HDD/SSD # and type | 2.5" x1 or 3.5'' x1 |
| Mechanical & Processing | |
| Dimensions | W:19.00"(482.6mm) x D:16.30"(412.8mm) x H:1.73"(43.9mm) |
| Applied M/B Form Factor | Micro-ATX |
| Material | Heavy Duty Cold-rolled Steel |
| Surface | Black Wet Paint with Texture Coat |
| Colour | Black / Customizable Colour |
| Power Solution Option | |
| Flex ATX Power Supply | Flex ATX 250/300/400 watts Power Supply(AC 110~240V auto-switching) |
