TAWA-T1Q20
1U Industrial Rackmount Chassis for ATX MB
· Excellent thermal solution featuring liquid CPU cooler and 3 x 4 cm fans (2-ball bearing).
· Support 2 x 2.5" SATA tray(full-height)
· Support 3 x expansion slot(Including: 1 low-profile expansion slot)
· Support 1U PSU
· Excellent thermal solution featuring liquid CPU cooler and 3 x 4 cm fans (2-ball bearing).
· Support 2 x 2.5" SATA tray(full-height)
· Support 3 x expansion slot(Including: 1 low-profile expansion slot)
· Support 1U PSU
Specification
| Front Panel | |
| Power Switch | 1 |
| LED Indicators | HDD x1; Power x1 |
| USB Port | 2 |
| HDD/SSD # and type | 2.5" x2(Full-height) |
| Back Panel | |
| Standard I/O Shield | With Universal I/O Shield |
| Expansion Slot | 2 standard + 1 low-profile |
| AC Socket | 1 |
| Internal Structure | |
| Liquid Cooling | Support up to TDP 210W for intel CPU or TDP 170W for AMD CPU |
| Air Cooling | 4cm Fan(2 Ball Bearing) x3 |
| Memory Height | Accept Standard Size |
| Mechanical & Processing | |
| Dimensions | W:19.00"(482.0mm) x D:22.72"(577.0mm) x H: 1.73"(44.0mm) |
| Applied M/B Form Factor | ATX MB |
| Material | SGCC |
| Surface | Black Wet Paint with Texture Coat |
| Colour | Black / Customizable Colour |
| Power Solution Option | |
| Flex ATX Power Supply | 1U Power Supply 600W/800W/1000W |
