TAWA-T2320
2U Industrial Rackmount Chassis for Micro-ATX MB(9.6"x9.6")
· Compact system design compatible with PCIe 5.0 riser for enhanced GPU computing power
· Support 4 x expansion slot for PCIe or PCI card
· Support 2 x 2.5" SATA tray
· Compact system design compatible with PCIe 5.0 riser for enhanced GPU computing power
· Support 4 x expansion slot for PCIe or PCI card
· Support 2 x 2.5" SATA tray
Specification
| Front Panel | |
| Power Switch | 1 |
| LED Indicators | HDD x1; Power x1 |
| USB Port | 2 |
| HDD/SSD # and type | 2.5"(Full-height) x 2 |
| Back Panel | |
| Standard I/O Shield | 1(Not Included) |
| Expansion Slot | 4(Low Profile) |
| AC Socket | 1 |
| Internal Structure | |
| System Cooling | 8cm Fan(2 Ball Bearing) x2 |
| Memory Height | Accept Standard Size |
| HDD/SSD # and type | 2.5" x1 |
| Mechanical & Processing | |
| Dimensions | W:17.00"(431.8mm) x D:15.60"(397.3mm) x H:3.46"(87.87mm) |
| Applied M/B Form Factor | Micro-ATX |
| Material | Heavy Duty Cold-rolled Steel |
| Surface | Black Wet Paint with Texture Coat |
| Colour | Black / Customizable Colour |
| Power Solution Option | |
| Power Supply | Flex PSU 250W/300W/400W/600W/850W |
