TAWA-T2409
2U Industrial Rackmount Chassis for ATX MB
Support up to 9 x 3.5" HDD
· Excellent cooling with 3 x 8cm fan + 2 x 6cm fan(2 ball bearing)
Support up to 9 x 3.5" HDD
· Excellent cooling with 3 x 8cm fan + 2 x 6cm fan(2 ball bearing)
Specification
| Front Panel | |
| Power Switch | 1 |
| LED Indicators | HDD x1; Power x1 |
| Back Panel | |
| Standard I/O Shield | 1(Not Included) |
| Expansion Slot | 7 |
| COM Port | 3 |
| Internal Structure | |
| System Cooling | 8cm Fan(2 Ball Bearing) x3 + 6cm Fan(2 Ball Bearing) x2 |
| Memory Height | Accept Standard Size |
| HDD/SSD # and type | 3.5'' x9 |
| Mechanical & Processing | |
| Dimensions | W:19.00"(482.6mm) x D: 21.11"(536.32mm) x H:3.46"(88mm) |
| Applied M/B Form Factor | ATX |
| Material | Heavy Duty Cold-rolled Steel |
| Surface | Black Wet Paint with Texture Coat |
| Colour | Black / Customizable Colour |
| Power Solution Option | |
| PSII Power Supply | PSII 300W / 400W / 500W Power Supply |
