TAWA-T3403


3U Industrial Rackmount Chassis for ATX MB

· Support up tp 3 x 5.25" ODD
· Support 7 x expansion slot
· Excellent cooling with 2 x 8cm fan(2 ball bearing)
· Support Flex PSU / 2U Redundant PSU



Specification

Front Panel
Power Switch 1(with LED indicator)
LED Indicators HDD x1
5.25" ODD 3
USB Port 2
System cooling 8cm Fan(2 Ball Bearing) x2
Back Panel
Expansion Slot 7
Standard I/O Shield 1(Not included)
Internal Structure
Memory Height Accept Standard Size
HDD/SSD # and type 3.5" x1
Mechanical & Processing
Dimensions W:19.00"(482.6mm) x D:19.60"(496.8mm) x H:5.20"(132.0mm)
Applied M/B Form Factor  ATX
Material SGCC
Surface Black Wet Paint with Texture Coat
Colour Black / Customizable Colour
Power Solution Option  1
FLEX Power Supply   250W/300W/400W/600W
Power Solution Option  2
Redundant Power Supply 2U Redundant Power Supply 300W/500W/800W
