TAWA-T4920
4U Industrial Rackmount Chassis for ISA/PICMG Backplane Board
· Support 2 x 3.5" SATA tray
· Excellent cooling with 3 x 12cm fan(2 ball bearing)
· Support 2 x 3.5" SATA tray
· Excellent cooling with 3 x 12cm fan(2 ball bearing)
Specification
| Front Panel | |
| Power Switch | 1 |
| LED Indicators | HDD x1; Power x1 |
| Expansion Slot | 14 |
| USB Port | 2 |
| HDD/SSD # and type | 3.5" x2 |
| Thermal Monitor Switch and LED | 1 |
| Power Jack | 1 |
| Back Panel | |
| System Cooling | 12cm Fan(2 Ball Bearing) x3 |
| Internal Structure | |
| Memory Height | Accept Standard Size |
| Mechanical & Processing | |
| Dimensions | W:19.00"(482.6mm) x D:18.10"(460.8mm) x H:6.92"(175.8mm) |
| Applied M/B Form Factor | PICMG / Back Plane |
| Material | Heavy Duty Cold-rolled Steel |
| Surface | Black Wet Paint with Texture Coat |
| Colour | Black / Customizable Colour |
| Power Solution Option | |
| PSII Power Supply | PSII 300W/400W/500W Power Supply |
