TAWA-T4980
4U Industrial Rackmount Chassis for ATX MB
· Support 8 x 2.5" SATA tray(full height)
· Support 7 x expansion slot
· Excellent cooling with 2 x 12cm fan(2 ball bearing)
· Support Mini Redundant PSU
· Support 8 x 2.5" SATA tray(full height)
· Support 7 x expansion slot
· Excellent cooling with 2 x 12cm fan(2 ball bearing)
· Support Mini Redundant PSU
Specification
| Front Panel | |
| Power Switch | 1 |
| LED Indicators | HDD x1; Power x1 |
| HDD/SSD # and type | 2.5" x8 |
| Standard I/O Shield | 1(Not Included) |
| Expansion Slot | 7 |
| Back Panel | |
| System Cooling | 12cm Fan(2 Ball Bearing) x2 |
| Internal Structure | |
| Memory Height | Accept Standard Size |
| Mechanical & Processing | |
| Dimensions | W:19.00"(481.6mm) x D:18.53"(470.8mm) x H:6.91"(175.6mm) |
| Applied M/B Form Factor | ATX |
| Material | Heavy Duty Cold-rolled Steel |
| Surface | Black Wet Paint with Texture Coat |
| Colour | Black / Customizable Colour |
| Power Solution Option | |
| Power Supply | Mini-Redundant PSU |
