TAWA-T9110
1.5U Industrial Rackmount Chassis for Mini-ITX MB
· Support 1 x 3.5" SATA tray
· Design for easy access from the front panel
· Support 1 x 3.5" SATA tray
· Design for easy access from the front panel
Specification
| Front Panel | |
| Power Switch | 1 |
| LED Indicators | HDD x1; Power x1 |
| USB 2.0 Port | 2 |
| Slim Optical Drive Slot | 1 |
| Audio In/Out | 1 |
| HDD/SSD # and type | 3.5" x1 |
| Back Panel | |
| Standard I/O Shield | 1(Not Included) |
| Expansion Slot | 1 |
| Internal Structure | |
| System Cooling | 4cm Fan(2 Ball Bearing) x2 |
| Memory Height | Accept Standard Size |
| HDD/SSD # and type | 2.5'' x2 |
| Mechanical & Processing | |
| Dimensions | W:19.00"(482.6mm) x D:10.02"(254.5mm) x H:2.56"(65mm) |
| Applied M/B Form Factor | Mini-ITX |
| Material | Aluminum Alloy and CRS |
| Surface | Black Wet Paint with Texture Coat |
| Colour | Black / Customizable Colour |
| Power Solution Option 1 | |
| Internal DC Power Board | C7(80W) DC Power Board |
| External AC Adapter | 60W: Input(AC 100~240V); Output(DC 12V@5A) |
| Power Solution Option 2 | |
| Internal DC Power Board | C7(80W) DC Power Board |
| External AC Adapter | 80W: Input(AC 100~240V); Output(DC 12V@6.67A) |
| Power Solution Option 3 | |
| Internal DC Power Board | C4(150W, 19V~24V) DC Power Boar |
| External AC Adapter | 90W: Input(AC 100~240V); Output(DC 19V@4.74A) |
| Power Solution Option 4 | |
| Internal DC Power Board | C4(150W, 19V~24V) DC Power Boar |
| External AC Adapter | 120W: Input(AC 100~240V); Output(DC 19V@6.32A) |
| Power Solution Option 5 | |
| Flex ATX Power Supply | Flex ATX 250/300/400watts Power Supply(AC 110~240V Auto-switching) |
