Specification
| Front Panel | |
| Power Switch | 1(With LED Indicator) |
| LED Indicators | HDD x1 |
| USB Port | 2 |
| HDD/SSD # and type Options | 2.5" x1 |
| Back Panel | |
| USB 3.0 Port | 2 |
| GPIO | 1 |
| COM | 4 |
| HDMI | 1 |
| ANT | 2 |
| Gigabit LAN | 2 |
| VGA | 1 |
| Audio In/Out | 1 |
| Internal Structure | |
| System Cooling | 1. Thermal Pads/Copper Thermal Block Combination: Which are positioned on the back-side of the top cover to transfer heat from CPU and chipset to top cover. 2. Aluminum-made Heat Sink Top Cover: With extensive heat sink surface from top cover of the chassis, KiwaTEK's fanless chassis provide excellent heat dissipation to eliminate the heat and solve thermal issues. |
| Copper Thermal Block | Positioned on the Back Side of Top Cover |
| Memory height | Accept standard size |
| Mechanical & Processing | |
| Dimensions | W:7.43"(188.8 mm) x D:6.61"(168 mm) x H:2.17"(55.0 mm) |
| Applied M/B Form Factor | 3.5 inch Embedded Board |
| Material | SGCC |
| Surface | Black Wet Paint with Texture Coat |
| Colour | Black / Customizable Colour |
| Power Solution Option | |
| External AC Adapter | 60W: Input(AC 100~240V); Output(DC 12V@5A) |
