TAWA-T48240


4U Industrial Rackmount Chassis for 12"x13" Server Board

· Support 24 x 3.5" SATA tray
· Excellent cooling with 3 x 12cm fan(2 ball bearing)
· Support 7 x expansion slot for PCIe or PCI card
· Support PSII PSU or mini redundant PSU



Specification

Front Panel
Power Switch 1
LED Indicators HDD x1; Power x1
USB Port 2
HDD/SSD # and type 3.5" x24
Back Panel
Standard I/O Shield 1(Not Included)
Expansion Slot
AC Socket 1
Internal Structure
System Cooling 12cm Fan(2 Ball Bearing) x3
Memory Height Accept Standard Size
HDD/SSD # and type 2.5" x 2
Mechanical & Processing
Dimensions W:19.00"(482.6 mm) x D:26.80"(681.8mm) x H:6.80"(171.8mm)
Applied M/B Form Factor  E-ATX
Material SGCC
Surface Black Wet Paint with Texture Coat
Colour Black / Customizable Colour
Power Solution Option 1
PSII Power Supply PSII 300W~1200W Power Supply
Power Solution Option 2
Power Supply Mini Redundant (300W+300W / 400W+400W)
